Taw qhia
Intelligent Network Management System rau CNG Gas Stations yog lub hauv paus software thiab kho vajtse -enabled platform tsim los saib xyuas, tswj, thiab optimize ntau compressed natural gas stations los ntawm ib puag ncig tswj.
Khoom Specification
|
Qeb |
Specification |
|
CPU |
Intel Atom quad -core |
|
Nco |
8GB DDR4 |
|
Cia |
64GB SLC eMMC |
|
Kev khiav hauj lwm Temp |
-40℃rau +75 degree |
|
I/O Ports |
2 x GbE, 4x RS485, 4x 4-20mA |
|
Kev ntsuas phom sij |
ATEX Zone 2 / CID2 |
|
Lub zog nkag |
9-36V DC nrog kev sib cais |
|
Thaub qab |
10 min supercapacitor |
|
Cov ntaub ntawv khaws cia |
180 hnub offline loging |
Technical Specification
|
Saib xyuas yam khoom |
Cov ntaub ntawv Source |
Hloov tshiab tus nqi |
|
Compressor vibration |
PLC sensors |
1s |
|
Mass flow rate |
Emerson / Endress + Hauser |
Lub sijhawm tiag tiag - |
|
Gas leak detection |
IR / catalytic sensors |
200ms event |
|
Valve routing xwm txheej |
Thawj tswj vaj huam sib luag |
1s |
|
Kub them nyiaj |
Ambient sensors |
5s |
|
Kev txheeb xyuas lub zog |
3-phase meters |
1s |
Daim ntawv thov & Compatibility
Ntau -Site Centralized Management:Huab- tus neeg xauj tsev architecture scaling ntawm 1 mus rau 500+ geographically dispersed CNG chaw nres tsheb.
Dispenser Protocol Integration:Kev them nyiaj yug haiv neeg rau IFSF dhau LonWorks/TCP-IP, Wayne DART, thiab Gilbarco ob-wire raws tu qauv.
PLC & Controller Interfacing:Daim ntawv teev npe ncaj qha rau Siemens S7-1200/1500, Allen-Bradley Micro800, thiab Omron industrial PLCs ntawm Modbus TCP/RTU.
Enterprise SCADA kev koom ua ke:Northbound cov ntaub ntawv streaming ntawm MQTT nrog Sparkplug B payloads thiab OPC UA rau kev cuam tshuam nrog koom nrog SCADA tes hauj lwm.
Retail & Fleet Forecourt Interfacing:XML/JSON API endpoints rau tiag-sijhawm cov ntaub ntawv synchronization nrog Gilbarco Passport, Wayne NAMOS, thiab fleet fuel card networks.
Muaj peev xwm tsim khoom
Traceability
Kev lag luam ntug rooj vag yog mapped nrog cov cim kho vajtse IDs txuas ncaj qha rau cov khoom siv firmware versions, AVL chipset batches, thiab pawg thawj coj saib -theem fais fab modules rau kev ua tiav lub neej taug qab.
72-Hour Industrial Burn-In Testing
Nruam tag nrho -load thermal kuaj ntawm 60℃thiab kev ntsuas hluav taws xob rau 72 teev ua ntej lub Hoobkas tshem tawm lub rooj vag kom txo cov menyuam mos tuag ntawm cov khoom siv hluav taws xob.
Batch Production
Kev tsim khoom khiav yog tsim los ntawm 50-300 units kom phim cov sij hawm xa mus rau theem.
Kev them nyiaj yug Installation
Kev tshuaj xyuas engineering tau ua tiav 14 hnub ua ntej xa mus, suav nrog hluav taws xob schematics, P&IDs, thiab network topology maps los tiv thaiv kev teeb tsa ntawm qhov chaw qeeb.
3-hnub nyob rau ntawm qhov chaw xa tawm raws tu qauv npog kev ntsuas lub voj voog, kev lees paub raws tu qauv, thiab kev sim ua tsis tiav hauv cheeb tsam uas siv qhov chaw ua ntej thauj khoom hauv lub vev xaib.
Kub- standby parallel deployment architecture khiav legacy forecourt controllers concurrently with INMS, kom ntseeg tau tias xoom pauv cov ntaub ntawv poob thiab xoom refueling kev cuam tshuam cuam tshuam thaum lub sij hawm kaw.
Kev xa tawm ntawm cov kab hluav taws xob txuas hluav taws xob, cov chaw faib IP chaw nyob, thiab daim ntawv teev npe Modbus tag nrho hauv 5 hnub ua haujlwm tom qab-commissioning.
Cov ntsiab lus lag luam
Yam tsawg kawg nkaus Order Quantity (MOQ):Kev yuav khoom pib pib ntawm qhov tsawg kawg nkaus ntawm 3 qhov chaw nres tsheb qhov rooj xa tawm pob khoom.
Software Licensing Structure:Tsau kev tso npe software txhua xyoo rau ib qhov chaw nres tsheb sib txuas, suav nrog thaj chaw ruaj ntseg, yuav tsum tau kho qhov tsis zoo, thiab cov nqi huab hosting uas tsis muaj cov nqi rov qab.
Hardware Warranty Policy:36- hli tus qauv ua ntej-hloov hloov warranty ntawm tag nrho cov qhov rooj kho vajtse, nrog rau kev xaiv txuas ntxiv mus txog 60 lub hlis.
SLA Teb Sijhawm:Tier-3 engineering teb nyob rau hauv 2 teev rau qhov tseem ceeb Priority-1 outages (chaw nres tsheb down) ntawm ib tug mob siab rau 24/7 technical helpdesk.
Kev Ua Raws Cai & Ntawv Pov Thawj:Muaj ntawv pov thawj rau cov chaw ua haujlwm txaus ntshai nrog cov ntaub ntawv muab thaum xa khoom rau FCC Tshooj 15, CE Mark, RoHS 3, ATEX / IECEx, thiab kev ua raws cai hauv cheeb tsam cellular carrier.
Kev them nyiaj yug Lifecycle
Peb lub hlis twg hloov tshiab ua haujlwm nrog nruj rov qab sib raug zoo rau cov chaw nres tsheb uas twb muaj lawm, thiab txhua hli kev ruaj ntseg thaj tso tawm rau kev txheeb xyuas CVE vulnerabilities.
Staged tej thaj chaw deb firmware hloov khoom dua tshiab nrog tsis siv neeg hauv zos dual -bootbank rollback raws li kev tuav tes pov thawj tsis ua hauj lwm los tiv thaiv chaw nres tsheb uptime.
Yam tsawg kawg 5-xyoo software txhawb nqa lub neej voj voog rau txhua qhov kev xa tawm, nrog rau cov txheej txheem kev sib txuas ntawm cov khoom siv kho vajtse.
System Documentation Bundle
1x Quad-Core Intel Atom muaj rooj vag hauv ATEX Zone 2 / CID2 stainless hlau enclosure.
Ua ntej-loaded Core Edge Computing Firmware nrog rau qhov kev xav rov qab hauv zos thiab 10 daim ntawv tso cai cov neeg siv khoom hauv zos.
Terminal strip wiring diagrams, IP address allocation charts, and Modbus register maps sheets delivered in 5 hnub ua hauj lwm tom qab-commissioning.
FAQ
Q: Dab tsi yog qhov system uptime ua tiav hauv kev xa tawm tiag?
A: Lub kaw lus tau pom qhov nruab nrab lub sijhawm nruab nrab ntawm 99.95% hauv ntau- qhov chaw tsav dav hlau tshaj 12-18 lub hlis ntawm kev ua haujlwm tsis tu ncua.
Q: Muaj pes tsawg lub chaw nres tsheb roj tuaj yeem ua ib qho kev xa tawm tuaj yeem txhawb nqa hauv kev xyaum?
A: Ib qho piv txwv hauv nruab nrab tuaj yeem tswj tau txog li 320 lub chaw ua haujlwm nyob rau hauv qhov txuas ntxiv tiag tiag - lub sijhawm saib xyuas. Cov ntaub ntawv latency tseem nyob rau hauv 800ms ntawm tag nrho cov load.
Q: Qhov ntsuas MTBF rau lub rooj vag kho vajtse yog dab tsi?
A: Field- kuaj MTBF rau kev lag luam rooj vag kho vajtse yog kwv yees li 62,000 teev ua haujlwm. Qhov no sib raug rau kwv yees li 7-8 xyoo ntawm kev ua haujlwm tas mus li hauv cov qauv kev lag luam.
Q: Yuav ua li cas cybersecurity nyob rau hauv tej thaj chaw deb kev sib txuas lus?
A: Txhua qhov chaw nres tsheb - mus rau - kev sib txuas lus huab tau ruaj ntseg siv TLS 1.3 encryption nrog daim ntawv pov thawj- raws li kev lees paub. Txhua lub cuab yeej muaj tus cim kho vajtse tshwj xeeb thiab tig cov yuam sij kev sib tham txhua 24 teev kom txo qis kev pheej hmoo cuam tshuam. Tsis tso cai hais kom txhaj tshuaj sim raug thaiv ntawm lub rooj vag firewall theem.
Q: Puas yog lub kaw lus puas tau lees paub nws tus kheej rau ib puag ncig txaus ntshai?
A: Yog lawm, kev xeem ntawv pov thawj tau ua los ntawm ATEX thiab IECEx lub chaw soj nstuam uas tau lees paub nrog cov ntaub ntawv ua raws li thaj tsam 2 ib puag ncig. Txhua qhov khoom xa tuaj suav nrog cov pob ntawv pov thawj uas tuaj yeem khi rau serial -cov lej kho vajtse. Daim ntawv pov thawj npog ob qho tib si hauv kev nyab xeeb thiab kev tiv thaiv hluav taws kub.
Q: Yuav ua li cas yog tias huab kev sib txuas tau ploj thaum lub sijhawm ua haujlwm roj?
A: Lub kaw lus hloov mus rau hom ntug hauv zos hauv 200 milliseconds tom qab kuaj pom kev poob. Tag nrho cov kev khiav hauj lwm tseem ceeb tseem siv cached tswj logic thiab synchronized thaum txuas rov qab. Tsis muaj cov ntaub ntawv hloov pauv tau ploj thaum lub sijhawm offline.
Q: Lub sijhawm ntau npaum li cas -chaw nres tsheb xa tawm feem ntau siv sijhawm?
A: Ib qho qauv nthuav tawm uas suav nrog 10-30 chaw nres tsheb feem ntau xav tau 3-5 lub lis piam suav nrog kev sib koom ua ke hauv network thiab ntawm - qhov chaw siv tau. Kev xa tawm loj dua li linearly nrog cov pab pawg sib txuas.
Q: Lub kaw lus puas tuaj yeem koom nrog PLC cov txheej txheem qub yam tsis muaj kev hloov pauv?
A: Yog lawm, lub kaw lus txhawb nqa ncaj qha Modbus daim ntawv qhia rau cov cuab yeej cuab tam Siemens, Allen-Bradley, thiab Omron PLC systems yam tsis muaj kev hloov kho vajtse. Feem ntau, kev sib koom ua ke yuav tsum tsuas yog firmware -qib kev hloov kho es tsis yog rewiring.
Q: Yuav ua li cas kuaj ua ntej xa khoom ntawm txhua chav tsev?
A: Txhua lub qhov rooj nkag mus rau 72-teev kev ntsuas kev ntxhov siab tas mus li ntawm qhov ntsuas kub siab txog 60 degree. Cov chav nyob kuj raug rau lub zog hloov pauv hloov pauv thiab I / O chaw nres nkoj kev ntxhov siab validation.
