Product Overview
Hydrogenation Kem yog lub siab -cov tshuaj tiv thaiv cov hlab ntsha uas tsim los rau cov txheej txheem hydrogenation hauv refining, petrochemical, thiab kev lag luam tshuaj zoo.
Nws ua kom tswj tau cov hydrogen-kua-catalyst kev sib cuam tshuam nyob rau hauv qhov kub thiab txias, kom ntseeg tau cov tshuaj tiv thaiv ruaj khov thiab cov khoom zoo ib yam.
Cov cuab yeej tsim kho raws li kev lees paub thoob ntiaj teb kev ntsuas lub nkoj tsim cov lej xws li ASME Tshooj VIII thiab tuaj yeem hloov kho raws li PED (EU Pressure Equipment Directive) cov cai.
Cov ntaub ntawv Parameter
|
Yam khoom / Khoom |
Standard Specification / Ntau |
|
Tsim Code |
ASME Sec. VIII Div. 1 / Div. 2, EN 13445 (PED) |
|
Tsim Siab |
High Pressure (Customized raws li cov ntaub ntawv txheej txheem) |
|
Tsim Kub |
Kub kub (Engineered ib thermal tsim yuav tsum) |
|
Sab hauv Diameter (ID) |
Yooj yim hnyav -cov haujlwm teeb tsa muaj |
|
Max Phab Ntsa Thickness |
Hnyav-phab ntsa fabrication muaj raws li kev ntsuas siab |
|
Max Lifting / Shipping Nyhav |
Loj -scale modular fabrication muaj peev xwm |
|
Cov ntaub ntawv hauv paus |
SA387 Gr.11/22/91, Duplex / Super Duplex Stainless Hlau, Carbon Steel |
|
Cladding / Overlay Khoom |
Inconel 625, SS347, SS316L (3 hli - 5} hli thickness) |
|
Corrosion Allowance |
Raws li cov ntaub ntawv txheej txheem (piv txwv li, 1.5mm - 3.0mm) |
Thov nco ntsoov:Raws li ASME-tso ntawv pov thawj cov chaw tsim khoom, tag nrho peb cov kab Hydrogenation yog 100% kev cai- engineered kom phim koj cov txheej txheem tshwj xeeb, tshuaj lom neeg, thiab cov cai hauv zos. Cov tsis tau saum toj no sawv cev rau peb tus qauv engineering peev xwm.
Core Technical Capabilities
Kev cai -engineered siv ASME-qib Cr-Mo steels (SA387 Gr.11/22/91) los yog Duplex alloys. Cov ntaub ntawv txwv nruj me ntsis ua raws li API RP 941 (Nelson Curves) txhawm rau tshem tawm High-Temperature Hydrogen Attack (HTHA) txaus ntshai.
Integrate ib 3 hli mus rau 5 hli sab hauv weld overlay ntawm Inconel 625 los yog SS347 los tiv thaiv lub hauv paus hlau tiv thaiv hnyav corrosion los ntawm hydrogen sulfide thiab organic acids.
Kev txheeb xyuas los ntawm kev soj ntsuam nruj nruj thiab nruj rau ib txoj haujlwm tshwj xeeb los xyuas kom meej cov txheej txheem kev nyab xeeb thiab txhawb kev tswj hwm ib puag ncig emissions.
Ua nyob rau hauv kev saib xyuas ntawm ASME Tso Cai Saib Xyuas nrog cov khoom siv taug qab txhawb nqa los ntawm EN 10204 3.1 lossis 3.2 mill daim ntawv pov thawj.
Hom Kev Siv & Txheej Txheem Media
Peb Cov Txheej Txheem Hydrogenation yog kev cai- tsim los tiv thaiv qhov chaw pabcuam hnyav hauv kev ua kom zoo, hydro- ua haujlwm, thiab huv lub zog, tshwj xeeb tshaj yog cov hom phiaj:
Cov Txheej Txheem
Hydrotreating (HDT), Hydrocracking (HDC), Hydrodesulfurization (HDS), thiab Nruam Catalytic Reforming (CCR).
Corrosive Media
Siab -siab hydrogen, hydrogen sulfide (H2S), dej qaub, amalgams, thiab organic acids.
Kev puas tsuaj
Tshwj xeeb engineered los tiv thaiv High-Tub kub Hydrogen Attack (HTHA), hydrogen-induced cracking (HIC), thiab sulfide stress cracking (SSC).
100% Tsis yog-Kev Ntsuam Xyuas Kev Puas Tsuaj (NDT) & Kev Tshuaj Xyuas
Txhua qhov Hydrogenation Kem tau ua haujlwm nruj, sau ntawv pov thawj zoo ua ntej tawm hauv peb qhov chaw:
Kev Ntsuas Volumetric
100% Radiographic Testing (RT) thiab Ultrasonic Testing (UT) raws li ASME Sec. V.
Kev kuaj saum npoo
100% Magnetic Particle Testing (MT) thiab Dye Penetrant Testing (PT).
Siab & Leak pov thawj
Hydrostatic Pressure Test ntawm 1.25 mus rau 1.5 npaug ntawm kev tsim siab, tuav rau tsawg kawg 2 teev, saib xyuas los ntawm cov ntsuas digital ntsuas.
Thib peb-Kev Tshuaj Xyuas Ib Tug (TPI)
Txais tos Bureau Veritas (BV), TUV, SGS, los yog Lloyd's Register rau cov ntaub ntawv traceability, vuam cav audit, thiab zaum kawg stamp pov thawj.
Advanced Engineering & Verification
Peb pab neeg ua haujlwm engineering siv kev lag luam - qauv tsim thiab simulation software los xyuas kom meej qhov ua tau raws li qhov tseeb, kev ua haujlwm ntev, thiab kev nyab xeeb ua ntej kev tsim khoom pib:
PV Elite / Compress:Rau qhov tseeb ASME Tshooj VIII Div. 1 & Div. 2 nkoj tsim, lub plhaub thickness xam, thiab flange ratings.
ANSYS (FEA):Rau Finite Element Analysis ntawm siab - thaj chaw kev nyuaj siab, hnyav nozzle loads, thiab complex thermal fatigue cycles.
AutoCAD & SolidWorks:Rau kev nthuav dav 3D modular piping layouts, structural skids, thiab fabrication - npaj khw kos duab.
MDR Documentation Package
Khoom siv
EN 10204 3.1/3.2 MTCs (Txhua qhov chaw siab)
Vuam
WPS, PQR, thiab WPQR cav
NDT & Tests
100% NDT (RT/UT/MT/PT), PWHT kab kos, Hydro & Helium xeem cav
Stamps
TPI Tso Lus Ceeb Toom & ASME U / U2 Stamp ntawv pov thawj
FAQ
Q: Qhov twg tsim qauv thiab - tog neeg soj ntsuam koj txhawb?
A: Peb tsim nruj me ntsis rau ASME Tshooj VIII (Div. 1 & 2) nrog U/U2 nyiaj muas thiab CE-PED cov qauv. Peb txhawb nqa thib peb -kev tshuaj xyuas los ntawm TUV, SGS, BV, thiab Lloyd's Register.
Q: Koj tuaj yeem lav qhov zoo ntawm kev tiv thaiv sab hauv -corrosion cladding li cas?
A: Peb siv automated strip overlay vuam (Inconel 625 / SS347) nrog qhov tsawg kawg nkaus thickness ntawm 3-5 hli. Txhawm rau kom muaj kev ncaj ncees ntawm metallurgical, peb tswj hwm kev tswj hwm nruj kom tswj tau cov tshuaj muaj pes tsawg leeg ntawm cov txheej txheej cladding. Tsis tas li ntawd, txhua square centimeter tau dhau 100% Surface Dye Penetrant Testing (PT) thiab Volumetric Ultrasonic Testing (UT) kom lav qhov tsis muaj qhov tsis zoo, tsis sib haum xeeb- tiv thaiv daim ntawv cog lus.
Q: Cov ntaub ntawv xeem dab tsi koj muab ua ntej xa khoom?
A: Koj yuav tau txais daim ntawv qhia txog MDR (Kev Tsim Cov Ntaub Ntawv) suav nrog EN 10204 3.1/3.2 cov ntaub ntawv pov thawj, PWHT (Kev Kho Kub Kub) cov kab kos, 100% NDT (RT/UT/MT/PT) cov ntaub ntawv, thiab thib peb- tog neeg pom hydro- kuaj thiab helium leak test logs.
Q: Dab tsi yog koj qhov siab tshaj plaws fabrication thiab nqa lub peev xwm?
A: Raws li ASME- muaj ntawv pov thawj cov chaw tsim khoom hnyav- cov hlab ntsha phab ntsa, peb lub chaw txhawb nqa loj - nplai, hnyav - tonnage fabrication. Txij li tag nrho cov kab ntawv yog 100% kev cai- engineering, thov qhia koj qhov hnyav, phab ntsa thickness, thiab txoj kab uas hla nrog peb pab neeg rau kev tshuaj xyuas engineering.
